Low Pass Filter stage: HDAM-SA2, SA3 current feedback Output Buffer: HDAM SA3 Headphone amp: HDAM-SA2 current feedback Frequency Response (Cust.): 2 Hz – 50 kHz Dynamic Range (SA): 109dB Signal to Noise Ratio (SA): 112dB Total Harmonic Distortion (SA): 0.0008% Frequency response: 2 Hz – 20 kHz Dynamic Range: 98 dB Signal to Noise Ratio: 104 dB Total Harmonic Distortion: 0.000015
CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC Yes / Yes / Yes / Yes / Yes / Yes CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta data No / Yes / Yes / Yes / Yes Data Disc Compatibility: DSD / WAV / ALAC <=5.6 / 192 / 96 DAC operation mode: USB B type / Coax / Optical Yes / Yes / Yes Asynchronous mode rear USB: Yes Bit-perfect transmission: Yes USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 DSD11.2 D-Bus: Yes Headphone Out: Yes Headphone Volume Control: Yes Remote Control: RC005PMSA Power Consumption: 47w Standby Consumption: 0.3w Auto Power off: Yes Detachable Power Cable: Yes Maximum Dimensions (W x D x H): 440 x 419 x 123mm Weight: 16.4Kg Carton Maximum Dimensions (W x D x H): 557 x 536 x 243mm Carton Weight (incl. product): 19.6Kg
